Wall Mounted Fan Coil Unit

Wall Mounted Fan Coil Unit

    It type does not occupy effective space, side air outlet form, matches with indoor decoration, easy disassembly and maintenance, reliable performance.

    Cooling Capacity: 6500-98000 BTU

    Email: support@aikegroupco.com

Product Description

The unit uses an EC fan motor and modulating valves can be integrated to allow for maximum output at minimum energy consumption. As a byproduct, the EC fan motor also provides extremely quiet operation. suitable for meeting rooms, halls and other occasions.

Wall mounted fan coils. Consumption reduced by 50% compared to the traditional motor. New version without on board valve. V3 version with 3-way ON/OFF valve on board.? Integrated master/slave function and serial interface. Remote control included.

Fan Coil Safety Performance Testing Room


FP Series Fan Coil Performance Parameter Table

● FP-34WA: Size: 740*460*240(mm); Effective Room: 10m2

● FP-51WA: Size: 840*460*240(mm); Effective Room: 15m2

● FP-68WA: Size: 940*460*240(mm); Effective Room: 20m2

● FP-85WA Size: 1040*460*240(mm); Effective Room: 25m2

● FP-102WA Size: 1140*460*240(mm); Effective Room: 30m2

● FP-136WA Size: 1340*460*240(mm); Effective Room: 35m2

● FP-170WA Size: 1640*460*240(mm); Effective Room: 40m2

● FP-204WA Size: 1840*460*240(mm); Effective Room: 50m2

● FP-238WA Size: 2040*460*240(mm); Effective Room: 60m2


Remarks:

1.The above performance parametersare measured according to the matching state without bringing back the bellows.The staticpressure at the outlet of KM unitis OPa.

2.Working condition parameters ofcoolingcapacity:inlet airdry bulbtemperature 7℃,wet bulb temperature 19.5℃,inlet water temperature7℃,water temperature difference 5℃.

3.Working condition parameters of heatsupply:the dy bulbtemperatureofinletair is 21℃,theinletwater temperature is60℃,and the lowof hot wateris the same as that of cooling.

4.Theaboveparameters comply withtheprovisions of GB/T 19232-2003.If the user has special requirements,please specify.


Using Effects



We have stock and can quickly pack, test and ship
